Chieftec Photon 650W RGB, ATX, 140 mm fläkt, 80PLUS White, löstagbara kablar
Chieftec CTG-650C-RGB
• Supports all renowned RGB synchronization systems
• Rainbow RGB fan with a +5V addressable LED connector
• High-Performance (85% Eff. @230V) RGB Gaming
The highly innovative Photon series are aimed at gamers and enthusiasts, looking for the ultimate in power, longevity, performance and of course, RGB lighting effects and all this at a highly affordable price. The +5V addressable LED connector of the PSU offers an extreme wide range of lighting modes and effects, supports all renowned RGB lighting synchronization systems such as ASUS™ AURA SYNC, MSI™ MYSTIC LIGHT SYNC, ASROCK™ POLYCHROME SYNC and GIGABYTE™ RGB FUSION.
Photon series in addition provide a vast number of predefined and MB-independent lighting modes and effects, which are set via a button on the rear of the power supply while a minute toggle switch, equally located on the rear of the PSU allows the choice between the M/B RGB control (if available) or the integrated modes and effects. With its modular cables and related vast amount of connectors, an efficiency of 85% @230V, coupled with its highly competitive price positioning, the models of the Photon series stand out as perfect RGB Gaming solutions.
• Rainbow RGB fan with a +5V addressable LED connector
• High-Performance (85% Eff. @230V) RGB Gaming
The highly innovative Photon series are aimed at gamers and enthusiasts, looking for the ultimate in power, longevity, performance and of course, RGB lighting effects and all this at a highly affordable price. The +5V addressable LED connector of the PSU offers an extreme wide range of lighting modes and effects, supports all renowned RGB lighting synchronization systems such as ASUS™ AURA SYNC, MSI™ MYSTIC LIGHT SYNC, ASROCK™ POLYCHROME SYNC and GIGABYTE™ RGB FUSION.
Photon series in addition provide a vast number of predefined and MB-independent lighting modes and effects, which are set via a button on the rear of the power supply while a minute toggle switch, equally located on the rear of the PSU allows the choice between the M/B RGB control (if available) or the integrated modes and effects. With its modular cables and related vast amount of connectors, an efficiency of 85% @230V, coupled with its highly competitive price positioning, the models of the Photon series stand out as perfect RGB Gaming solutions.
Total effekt
650 W
Art.nr: 58012
Hyvelgatan
Beställningsvara
Slite Utveckling
Beställningsvara
Fjärrlager
Fjärrlager
Beställningsvara
1 549 kr
2,38 kr / W
Produktspecifikation
Strömtillförsel
Effektivitet | 85% |
Effekt skyddsfunktioner | Överspänning, Överbelastning, Kortslutning, Underspänning |
Kombinerad effekt (+3,3 V) | 120 W |
Kombinerad effekt (+5 V) | 120 W |
Kombinerad effekt (+5 VSB) | 12,5 W |
Max utström (+3,3 V) | 22 A |
Max utström (+5 V) | 22 A |
Max utström (+5 VSB) | 2,5 A |
Max utström (-12V) | 0,3 A |
Max utström (+12 V1) | 26 A |
Växelström Frekvens | 50 Hz |
Total effekt | 650 W |
Anslutningar
Antalet SATA strömkontakter | 6 |
CPU strömkontakt (4 +4 pin) | Ja |
CPU-strömkabelns längd | 60 cm |
Diskettenhet strömkontakt | 2 |
Moderkort strömkontakt | 24-pin ATX |
PCI Express strömkontakter (6 +2 pin) | 4 |
PCI Express-nätkabelns längd | 55 cm |
SATA-nätkabelns längd | 150,450 mm |
Tillbehörsnätkabelns (Molex) längd | 150,450 mm |
Periferiska (Molex) strömkontakter (4-pin) | 4 |
Design
Fläktdiameter | 12 cm |
Produktens färg | Svart |
Kylning typ | Aktiv |
Belysning | Ja |
Belysningsfärg | Blå, Grön, Röd |
Prestanda
Strömförsörjningsenhet formfaktor | ATX |
Strömförsörjningsenhet formfaktor | PS/2 |
Ändamål | PC |
Vikt & dimension
Bredd | 150 mm |
Djup | 140 mm |
Höjd | 87 mm |
Vikt | 2,14 kg |
Fabrikat
Tillverkare | Chieftec |
SKU | CTG-650C-RGB |
Produktlänk | https://www.chieftec.eu/products-detail/172/PHOTON_SERIES |
