MSI PRO B850-P WIFI, AMD AM5, ATX, 4xPCI Express, 4xDDR5, 3xM.2 + SATA3 RAID, HDMI, USB-C, 5GbE LAN, WiFi 7, Bluetooth 5.4
MSI PRO B850-P WIFI
PRO B850-P WIFI
PRO B850-P WIFI offers a simple design with a harmonious silver color scheme that perfectly matches both white and black PC builds. It is engineered with many exclusive features of MSI, a true Wi-Fi 7 with EZ Antenna, 5G LAN, PCIe 5.0 M.2 with EZ M.2 Shield Frozr II, and Supplemental PCIe Power, ready for the AMD Ryzen™ 9000 series processors.
PRO B850-P WIFI offers a simple design with a harmonious silver color scheme that perfectly matches both white and black PC builds. It is engineered with many exclusive features of MSI, a true Wi-Fi 7 with EZ Antenna, 5G LAN, PCIe 5.0 M.2 with EZ M.2 Shield Frozr II, and Supplemental PCIe Power, ready for the AMD Ryzen™ 9000 series processors.
Art.nr: 86309
Hyvelgatan
Beställningsvara (ber. 2025-12-23)
Slite Utveckling
Beställningsvara (ber. 2025-12-23)
Fjärrlager
Fjärrlager
{$antal} {$enhet}
2 490 kr
Produktspecifikation
Egenskaper
| Moderkort formfaktor | ATX |
| Moderkort kretstyp | AMD B850 |
| Moderkort chipset familj | AMD |
| Ljudchipp | Realtek ALC897 |
| Ljudutgångskanaler | 7.1 kanaler |
Processor
| Processorsockel | AM5-sockel |
Anslutningsmöjligheter
| Antal HDMI | 1 |
| HDMI-version | 2.1 |
| Antal USB 3.2 Gen 2 (3.1 Gen 2) typ A-portar | 2 |
| Antal USB 3.2 Gen 1 (3.1 Gen 1) typ A-portar | 1 |
| Antal USB 3.2 Gen 2 (3.1 Gen 2) typ C-portar | 3 |
| Antal USB 2.0 anslutningar | 4 |
| Antal LAN (RJ-45) anslutningar | 1 |
Expansionsplatser
| PCI Express x16 (Gen 3.x)-kortplatser | 2 |
| PCI Express x16 (Gen 5.x) platser | 1 |
| PCI Express x16 (Gen 4.x) platser | 1 |
| Antal M.2 (M)-platser | 3 |
| 2nd M.2 highest PCI Express generation | 4.0 |
| 3rd M.2 highest PCI Express generation | 4.0 |
| 1st M.2 highest PCI Express generation | 5.0 |
Internal I/O
| USB 3.2 Gen 1 (3.1 Gen 1)-anslutningar | 4 |
| Antal SATA III kontakter | 4 |
| USB 2.0 anslutning | 4 |
| RGB LED stiftlist | Ja |
| USB 3.2 Gen 2 (3.1 Gen 2)-anslutningar | 1 |
Lagringskontroll
| RAID-stöd | Ja |
| Lagringsenhetsgränssnitt som stöds | M.2, Micro SATA III |
| RAID-nivåer | 0, 1 |
| Antal lagringsenheter som stöds | 7 |
Minne
| Antal minnesplatser | 4 |
| Minnets hastigheter | 4800,5600,8200 MHz |
| Maximalt internminne | 256 GB |
| Minneskanaler stöd | Dubbla kanaler |
| Minnesklockhastighet som stöds (max) | 8200 MHz |
| Minnestyper som stöds | DDR5-SDRAM |
Nätverk
| Nätverksansluten (Ethernet) | Ja |
| Typ av ethernet-gränssnitt | 5 Gigabit Ethernet |
| Wi-Fi | Ja |
| Wi-Fi-standard | Wi-Fi 7 (802.11be) |
| Bluetooth | Ja |
| Bluetooth-version | 5.4 |
Vikt & dimension
| Bredd | 243,8 mm |
| Djup | 304,8 mm |
Fabrikat
| Tillverkare | MSI |
| SKU | PRO B850-P WIFI |
| Produktlänk | https://www.msi.com/Motherboard/PRO-B850-P-WIFI |
